QUADRON

Our carton shuttle robot, that swiftly enables accelerated picking, order sequencing and order fulfilment, driving the storage efficiency through the ceiling



Built to be Flexible, Reliable and the Safest on Earth



High Throughputs

Quadron system along with vertical lifts and WCS gives quick turnaround cycles



Load Optimisation

Load carrying capacity of upto 50 kg accompanied with a speed of 3 m/sec





Varied Load Handling

Adjustable claws allow multiple load formats in one aisle





Operating Temperature

Easy and effective operation across a wide range of temperatures from -30℃ to 50 ℃





Height Utilization

Highly modular structure allows the system to go as high as 15 meters and storage of up to 12 levels



Scalable

With Quadron, aisle length can be expanded to a staggering 100 meters, depending on the volume and required throughputs



Quadron Process – 1 / 3

Quadron runs along the narrow aisles and drops the load at the destination point



Quadron Process – 2 / 3

In case of retrieval, Quadron pulls the load using telescopic arms



Quadron Process – 3 / 3

Double-deep system allows storage of varied types of loads in a single aisle

A title

Image Box text

A title

Image Box text

A title

Image Box text

Speed & Performance

Payload capacity: 50 Kg

Loaded/Empty Speed: 3 m/s

Placing Cycle time for double deep: 10-12 sec

Retrieval Cycle time for double deep: 8-10 sec

Position Accuracy: +/- 3 mm through barcode/positioning sensors

Physical attributes

Shuttle Dimensions: 1242 mm x 900 mm x 305.2 mm

Extension: 1342 mm

Carton Dimensions (LxW): 600 mm x 400 mm

Shuttle Colour: White & Blue
