Built to be Flexible, Reliable and the Safest on Earth
Height Utilization
Increased number of height levels (as high as 15) with each level having mother and child shuttles for optimal space utilization
High Throughput
Offers an increased throughput of 60-70 pallets/hour, powered by a Mother shuttle carrying speed of up to 3 m/s and Child Shuttle carrying speed of 0.8-1.1 m/s
Varied Load Handling
Multi-Pro system handles varied load formats with a payload of 1500kg
High Operating Time
Operational for 10 hours with one recharge cycle and a fast battery charger that charges it 100% in 30 minutes
Safety
100% accurate positioning with respect to racks facilitated by Multi-Pro and Cruiser, augmenting the safety features
Convenient & Flexible
Effective planning, informed decision-making, and flexible material handling enabled by in-house built control system
Multi-Pro’s Process – 1 / 3
Multi-Pro system takes the pallet load from the vertical lift and moves to the required location
Multi-Pro’s Process- 2 / 3
At the specified aisle, Cruiser goes to the required location and performs storage operation
Multi-Pro’s Process – 3 / 3
In case of retrieval, Cruiser brings the pallet from the specified aisle to the Multi-pro channel
