CRUISER

Our pallet shuttle robot that enables vertical space utilization, facilitates FIFO & LIFO operations for safe and faster pallet load movements





Built to be Flexible, Reliable and the Safest on Earth



Improved Accuracy

Increases picking accuracy levels to 99.99% + ensures safety of operations & ergonomics





Cost-Effective

Vertical utilization of floor space helps in minimizing rental & maintenance costs





Space Utilization

Narrow aisles of the pallet shuttle shelving allow for more storage space and the channel length can go as deep as 40m





High Productivity

Increased number of cycles/hour enabled by continuous loading & unloading





Safety

Equipped with bumpers and safety sensors, cruiser provides safe collaboration to work alongside humans





Ease of Operation

With simple and clear instructions it can be easily operated with any android smart device





Utilization of vertical space through dense racking system



After processing the command, Cruiser takes the pallet load to the given location and stores it



In case of retrieval, Cruiser goes to specified location, and brings the pallet back



Equipped with bumpers and safety sensors, Cruiser avoids collision with other pallets or humans and running out of channel

Our impact

A title

Image Box text

A title

Image Box text

A title

Image Box text

Speed &Performance

Payload capacity: 1000/1500 kg
Speed Unloaded: 1.1m/sec
Speed Loaded: 0.8m/sec
Power supply: DC 24 V
Travelling Motor Power: 1.0 KW

Other Features

Pallet Dimensions:

1000mm x 800mm
1000mm x 1000mm
1000mm x 1200mm
1200mm x 1200mm

Battery Capacity: 24 V 58Ah
Battery Operational Capacity: 4/10 H
Communication Mode: WIFI (2.5GHZ, 5 GHZ)
Control: PLC based
Remote Access / Support VPN Access:Yes





Accessories



Controlling Tab

Processor: Qualcomm MSM8909
OS: Android 8.1 Oreo
RAM: 2GB
Dimensions (mm): 193.04 x 132.08 x 12.70



Battery Charger

Battery Charging Time: 5/0.5 H



Battery

Battery Capacity: 24 V 78/50Ah
Battery Operational Capacity: 4/10 H
